JBL SOUNDGEAR FRAMES ONXY

Design & Build

• Frame Material: TR90 plastic
• Hinge: Stainless steel (SUS316)
• Temple Housing: Polycarbonate (PC)
• Water Resistance: IP54 (splash and dust resistant)
• Lens: UV-blocking polycarbonate (swappable for prescription lenses)
• Power On/Off: Opens to turn on, closes to turn off

Audio Performance

• Driver Size: 25mm x 9mm dynamic drivers
• Frequency Response: 100Hz – 18kHz
• Sensitivity: 114 dB SPL @ 1kHz
• Max SPL: 90 dB
• Microphone Sensitivity: -38 dBV/Pa
• Impedance: 20 ohms

Battery & Charging

• Battery Type: Lithium-ion, 110mAh per temple
• Playback Time: Up to 8 hours
• Charging Time: Approx. 2 hours
• Charging Port: USB Type-C (Y-cable)

Connectivity

• Bluetooth Version: 5.2
• Transmission Range: ~10 meters
• Frequency Band: 2.4GHz
• Supported Codecs: SBC
• Touch Controls: On both temples (volume, music, calls)

Dimensions

• Square Frame: 160.21 × 152.54 × 50.83 mm
• Round Frame: 160.87 × 150.54 × 53.68 mm
• Weight: Around 45g

In the Box

• JBL Soundgear Frames
• Carrying Case
• USB Type-C Charging Cable (Y-shaped)
• Quick Start Guide
• Warranty Card
• Safety Instructions
